• Automatic rain shutoff prevents overwatering due to natural precipitation
• Robust, reliable design reduces service callbacks
• Moisture sensing disks work in a variety of climates
• Different sensor mounts permit speed and flexibility on the job site
• The latching hinge maintains alignment

Mechanical Properties

• Multiple rainfall settings from 1⁄8"– ¾" (5 - 20 mm) are quick and easy with just the twist of a dial
• An adjustable vent ring helps control drying time
• A high-grade, UV-resistant polymer body resists the elements
• Comes with a 5" latching aluminum bracket
• Not compatible with ESP-SMT or ESP-SMTe controllers

Electrical Specifications

• Application: Suitable for low voltage 24 VAC control circuits and 24 VAC pump start relay circuits. Not recommended for use with high voltage pump start, pump start relay circuits, or devices
• Switch electrical rating: 3A @ 125/250 VAC
• Capacity: Electrical rating suitable for use with up to ten 24 VAC,7 VA solenoid valves per station, plus one master valve
• Wire: 25' (7.6 m) length of #20, 2 conductor UV resistant extension wire
